Analyze stroke measurements
This commit is contained in:
parent
87a17bff73
commit
69a11cfe94
BIN
doc/Millimar--3723046--BA--C1208-C1216-C1240--FR--2016-11-08.pdf
Normal file
BIN
doc/Millimar--3723046--BA--C1208-C1216-C1240--FR--2016-11-08.pdf
Normal file
Binary file not shown.
BIN
doc/tmp3m0cvmue_7888038c-cdc8-48d8-a837-35de02760685.pdf
Normal file
BIN
doc/tmp3m0cvmue_7888038c-cdc8-48d8-a837-35de02760685.pdf
Normal file
Binary file not shown.
BIN
figs/CE0EF55E-07B7-461B-8CDB-98590F68D15B.jpeg
Normal file
BIN
figs/CE0EF55E-07B7-461B-8CDB-98590F68D15B.jpeg
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 2.4 MiB |
BIN
figs/apa_d_vs_V_1s.pdf
Normal file
BIN
figs/apa_d_vs_V_1s.pdf
Normal file
Binary file not shown.
BIN
figs/apa_d_vs_V_1s.png
Normal file
BIN
figs/apa_d_vs_V_1s.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 89 KiB |
BIN
figs/apa_d_vs_V_2s.pdf
Normal file
BIN
figs/apa_d_vs_V_2s.pdf
Normal file
Binary file not shown.
BIN
figs/apa_d_vs_V_2s.png
Normal file
BIN
figs/apa_d_vs_V_2s.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 94 KiB |
BIN
figs/apa_d_vs_V_3s.pdf
Normal file
BIN
figs/apa_d_vs_V_3s.pdf
Normal file
Binary file not shown.
BIN
figs/apa_d_vs_V_3s.png
Normal file
BIN
figs/apa_d_vs_V_3s.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 94 KiB |
BIN
figs/apa_stroke_time_1s.pdf
Normal file
BIN
figs/apa_stroke_time_1s.pdf
Normal file
Binary file not shown.
BIN
figs/apa_stroke_time_1s.png
Normal file
BIN
figs/apa_stroke_time_1s.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 45 KiB |
BIN
figs/apa_stroke_time_2s.pdf
Normal file
BIN
figs/apa_stroke_time_2s.pdf
Normal file
Binary file not shown.
BIN
figs/apa_stroke_time_2s.png
Normal file
BIN
figs/apa_stroke_time_2s.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 49 KiB |
BIN
figs/apa_stroke_voltage_time.pdf
Normal file
BIN
figs/apa_stroke_voltage_time.pdf
Normal file
Binary file not shown.
BIN
figs/apa_stroke_voltage_time.png
Normal file
BIN
figs/apa_stroke_voltage_time.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 25 KiB |
@ -3,7 +3,7 @@
|
||||
"http://www.w3.org/TR/xhtml1/DTD/xhtml1-strict.dtd">
|
||||
<html xmlns="http://www.w3.org/1999/xhtml" lang="en" xml:lang="en">
|
||||
<head>
|
||||
<!-- 2021-03-15 lun. 11:35 -->
|
||||
<!-- 2021-03-16 mar. 14:30 -->
|
||||
<meta http-equiv="Content-Type" content="text/html;charset=utf-8" />
|
||||
<title>Amplifier Piezoelectric Actuator APA300ML - Test Bench</title>
|
||||
<meta name="author" content="Dehaeze Thomas" />
|
||||
@ -39,33 +39,40 @@
|
||||
<h2>Table of Contents</h2>
|
||||
<div id="text-table-of-contents">
|
||||
<ul>
|
||||
<li><a href="#org0eb094b">1. Model of an Amplified Piezoelectric Actuator and Sensor</a></li>
|
||||
<li><a href="#org6f9ba21">2. Geometrical Measurements</a>
|
||||
<li><a href="#orgeae854b">1. Model of an Amplified Piezoelectric Actuator and Sensor</a></li>
|
||||
<li><a href="#org5126568">2. Geometrical Measurements</a>
|
||||
<ul>
|
||||
<li><a href="#org8044086">2.1. Measurement Setup</a></li>
|
||||
<li><a href="#org4293145">2.2. Measurement Results</a></li>
|
||||
<li><a href="#orge477895">2.1. Measurement Setup</a></li>
|
||||
<li><a href="#orgf6e38fd">2.2. Measurement Results</a></li>
|
||||
</ul>
|
||||
</li>
|
||||
<li><a href="#org50d4352">3. Electrical Measurements</a></li>
|
||||
<li><a href="#orgb8a1481">4. Stiffness measurement</a>
|
||||
<li><a href="#org3da2e64">3. Electrical Measurements</a></li>
|
||||
<li><a href="#orgcd8f0b8">4. Stiffness measurement</a>
|
||||
<ul>
|
||||
<li><a href="#org21bc9b2">4.1. APA test</a></li>
|
||||
<li><a href="#org20509de">4.1. APA test</a></li>
|
||||
</ul>
|
||||
</li>
|
||||
<li><a href="#orgb3154e0">5. Test-Bench Description</a></li>
|
||||
<li><a href="#orgac581ad">6. Measurement Procedure</a>
|
||||
<li><a href="#orgc5606b4">5. Stroke measurement</a>
|
||||
<ul>
|
||||
<li><a href="#orge00396f">6.1. Stroke Measurement</a></li>
|
||||
<li><a href="#org66ac5bb">6.2. Stiffness Measurement</a></li>
|
||||
<li><a href="#orgee2d3e8">6.3. Hysteresis measurement</a></li>
|
||||
<li><a href="#orge6e89ca">6.4. Piezoelectric Actuator Constant</a></li>
|
||||
<li><a href="#orge970d07">6.5. Piezoelectric Sensor Constant</a></li>
|
||||
<li><a href="#org86b3954">6.6. Capacitance Measurement</a></li>
|
||||
<li><a href="#orgc5205df">6.7. Dynamical Behavior</a></li>
|
||||
<li><a href="#org2f73a1b">6.8. Compare the results obtained for all 7 APA300ML</a></li>
|
||||
<li><a href="#org676705f">5.1. Voltage applied on one stack</a></li>
|
||||
<li><a href="#orgf6d51af">5.2. Voltage applied on two stacks</a></li>
|
||||
<li><a href="#org5fada7f">5.3. Voltage applied on all three stacks</a></li>
|
||||
</ul>
|
||||
</li>
|
||||
<li><a href="#org175e8d0">7. Measurement Results</a></li>
|
||||
<li><a href="#org3248c3e">6. Test-Bench Description</a></li>
|
||||
<li><a href="#orgabbb81c">7. Measurement Procedure</a>
|
||||
<ul>
|
||||
<li><a href="#orge3152f8">7.1. Stroke Measurement</a></li>
|
||||
<li><a href="#orgc1cf00d">7.2. Stiffness Measurement</a></li>
|
||||
<li><a href="#org61adc4b">7.3. Hysteresis measurement</a></li>
|
||||
<li><a href="#org3c6cfed">7.4. Piezoelectric Actuator Constant</a></li>
|
||||
<li><a href="#org9c52d3c">7.5. Piezoelectric Sensor Constant</a></li>
|
||||
<li><a href="#org30f8839">7.6. Capacitance Measurement</a></li>
|
||||
<li><a href="#org7549456">7.7. Dynamical Behavior</a></li>
|
||||
<li><a href="#org51816a1">7.8. Compare the results obtained for all 7 APA300ML</a></li>
|
||||
</ul>
|
||||
</li>
|
||||
<li><a href="#org0b4e69a">8. Measurement Results</a></li>
|
||||
</ul>
|
||||
</div>
|
||||
</div>
|
||||
@ -90,21 +97,21 @@ This include:
|
||||
</ul>
|
||||
|
||||
|
||||
<div id="org664d1fb" class="figure">
|
||||
<div id="org6bbfe2e" class="figure">
|
||||
<p><img src="figs/apa300ML.png" alt="apa300ML.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 1: </span>Picture of the APA300ML</p>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org0eb094b" class="outline-2">
|
||||
<h2 id="org0eb094b"><span class="section-number-2">1</span> Model of an Amplified Piezoelectric Actuator and Sensor</h2>
|
||||
<div id="outline-container-orgeae854b" class="outline-2">
|
||||
<h2 id="orgeae854b"><span class="section-number-2">1</span> Model of an Amplified Piezoelectric Actuator and Sensor</h2>
|
||||
<div class="outline-text-2" id="text-1">
|
||||
<p>
|
||||
Consider a schematic of the Amplified Piezoelectric Actuator in Figure <a href="#orgc9df44d">2</a>.
|
||||
Consider a schematic of the Amplified Piezoelectric Actuator in Figure <a href="#org2844129">2</a>.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="orgc9df44d" class="figure">
|
||||
<div id="org2844129" class="figure">
|
||||
<p><img src="figs/apa_model_schematic.png" alt="apa_model_schematic.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 2: </span>Amplified Piezoelectric Actuator Schematic</p>
|
||||
@ -129,11 +136,11 @@ We wish here to experimental measure \(g_a\) and \(g_s\).
|
||||
</p>
|
||||
|
||||
<p>
|
||||
The block-diagram model of the piezoelectric actuator is then as shown in Figure <a href="#orgc4bba98">3</a>.
|
||||
The block-diagram model of the piezoelectric actuator is then as shown in Figure <a href="#org5ba1265">3</a>.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="orgc4bba98" class="figure">
|
||||
<div id="org5ba1265" class="figure">
|
||||
<p><img src="figs/apa-model-simscape-schematic.png" alt="apa-model-simscape-schematic.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 3: </span>Model of the APA with Simscape/Simulink</p>
|
||||
@ -141,22 +148,30 @@ The block-diagram model of the piezoelectric actuator is then as shown in Figure
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org6f9ba21" class="outline-2">
|
||||
<h2 id="org6f9ba21"><span class="section-number-2">2</span> Geometrical Measurements</h2>
|
||||
<div id="outline-container-org5126568" class="outline-2">
|
||||
<h2 id="org5126568"><span class="section-number-2">2</span> Geometrical Measurements</h2>
|
||||
<div class="outline-text-2" id="text-2">
|
||||
<p>
|
||||
The received APA are shown in Figure <a href="#org1895ec7">4</a>.
|
||||
</p>
|
||||
|
||||
<div id="org939ac64" class="figure">
|
||||
|
||||
<div id="org1895ec7" class="figure">
|
||||
<p><img src="figs/IMG_20210224_143500.jpg" alt="IMG_20210224_143500.jpg" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 4: </span>Received APA</p>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org8044086" class="outline-3">
|
||||
<h3 id="org8044086"><span class="section-number-3">2.1</span> Measurement Setup</h3>
|
||||
<div id="outline-container-orge477895" class="outline-3">
|
||||
<h3 id="orge477895"><span class="section-number-3">2.1</span> Measurement Setup</h3>
|
||||
<div class="outline-text-3" id="text-2-1">
|
||||
<p>
|
||||
The flatness corresponding to the two interface planes are measured as shown in Figure <a href="#org9fff0ac">5</a>.
|
||||
</p>
|
||||
|
||||
<div id="org43d857b" class="figure">
|
||||
|
||||
<div id="org9fff0ac" class="figure">
|
||||
<p><img src="figs/IMG_20210224_143809.jpg" alt="IMG_20210224_143809.jpg" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 5: </span>Measurement Setup</p>
|
||||
@ -164,11 +179,11 @@ The block-diagram model of the piezoelectric actuator is then as shown in Figure
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org4293145" class="outline-3">
|
||||
<h3 id="org4293145"><span class="section-number-3">2.2</span> Measurement Results</h3>
|
||||
<div id="outline-container-orgf6e38fd" class="outline-3">
|
||||
<h3 id="orgf6e38fd"><span class="section-number-3">2.2</span> Measurement Results</h3>
|
||||
<div class="outline-text-3" id="text-2-2">
|
||||
<p>
|
||||
Height (Z) measurements:
|
||||
The height (Z) measurements at the 8 locations (4 points by plane) are defined below.
|
||||
</p>
|
||||
<div class="org-src-container">
|
||||
<pre class="src src-matlab">apa1 = 1e<span class="org-type">-</span>6<span class="org-type">*</span>[0, <span class="org-type">-</span>0.5 , 3.5 , 3.5 , 42 , 45.5, 52.5 , 46];
|
||||
@ -184,7 +199,7 @@ apa = {apa1, apa2, apa3, apa4, apa5, apa6, apa7b};
|
||||
</div>
|
||||
|
||||
<p>
|
||||
X/Y Positions of the 8 measurement points:
|
||||
The X/Y Positions of the 8 measurement points are defined below.
|
||||
</p>
|
||||
<div class="org-src-container">
|
||||
<pre class="src src-matlab">W = 20e<span class="org-type">-</span>3; <span class="org-comment">% Width [m]</span>
|
||||
@ -196,6 +211,9 @@ pos = [[<span class="org-type">-</span>L<span class="org-type">/</span>2 <span c
|
||||
</pre>
|
||||
</div>
|
||||
|
||||
<p>
|
||||
Finally, the flatness is estimated by fitting a plane through the 8 points using the <code>fminsearch</code> command.
|
||||
</p>
|
||||
<div class="org-src-container">
|
||||
<pre class="src src-matlab">apa_d = zeros(1, 7);
|
||||
<span class="org-keyword">for</span> <span class="org-variable-name"><span class="org-constant">i</span></span> = <span class="org-constant">1:7</span>
|
||||
@ -207,43 +225,57 @@ pos = [[<span class="org-type">-</span>L<span class="org-type">/</span>2 <span c
|
||||
</pre>
|
||||
</div>
|
||||
|
||||
<table id="org2443ab1" border="2" cellspacing="0" cellpadding="6" rules="groups" frame="hsides">
|
||||
<p>
|
||||
The obtained flatness are shown in Table <a href="#org36f0e82">1</a>.
|
||||
</p>
|
||||
|
||||
<table id="org36f0e82" border="2" cellspacing="0" cellpadding="6" rules="groups" frame="hsides">
|
||||
<caption class="t-above"><span class="table-number">Table 1:</span> Estimated flatness</caption>
|
||||
|
||||
<colgroup>
|
||||
<col class="org-left" />
|
||||
|
||||
<col class="org-right" />
|
||||
</colgroup>
|
||||
<thead>
|
||||
<tr>
|
||||
<th scope="col" class="org-right">Flatness [um]</th>
|
||||
<th scope="col" class="org-left"> </th>
|
||||
<th scope="col" class="org-right"><b>Flatness</b> \([\mu m]\)</th>
|
||||
</tr>
|
||||
</thead>
|
||||
<tbody>
|
||||
<tr>
|
||||
<td class="org-left">APA 1</td>
|
||||
<td class="org-right">8.9</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 2</td>
|
||||
<td class="org-right">3.1</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 3</td>
|
||||
<td class="org-right">9.1</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 4</td>
|
||||
<td class="org-right">3.0</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 5</td>
|
||||
<td class="org-right">1.9</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 6</td>
|
||||
<td class="org-right">7.1</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 7</td>
|
||||
<td class="org-right">18.7</td>
|
||||
</tr>
|
||||
</tbody>
|
||||
@ -252,10 +284,10 @@ pos = [[<span class="org-type">-</span>L<span class="org-type">/</span>2 <span c
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org50d4352" class="outline-2">
|
||||
<h2 id="org50d4352"><span class="section-number-2">3</span> Electrical Measurements</h2>
|
||||
<div id="outline-container-org3da2e64" class="outline-2">
|
||||
<h2 id="org3da2e64"><span class="section-number-2">3</span> Electrical Measurements</h2>
|
||||
<div class="outline-text-2" id="text-3">
|
||||
<div class="note" id="org262a984">
|
||||
<div class="note" id="org7758b1f">
|
||||
<p>
|
||||
The capacitance of the stacks is measure with the <a href="https://www.gwinstek.com/en-global/products/detail/LCR-800">LCR-800 Meter</a> (<a href="doc/DS_LCR-800_Series_V2_E.pdf">doc</a>)
|
||||
</p>
|
||||
@ -263,7 +295,7 @@ The capacitance of the stacks is measure with the <a href="https://www.gwinstek.
|
||||
</div>
|
||||
|
||||
|
||||
<div id="orgdaa55e5" class="figure">
|
||||
<div id="org66db1d7" class="figure">
|
||||
<p><img src="figs/IMG_20210312_120337.jpg" alt="IMG_20210312_120337.jpg" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 6: </span>LCR Meter used for the measurements</p>
|
||||
@ -273,11 +305,11 @@ The capacitance of the stacks is measure with the <a href="https://www.gwinstek.
|
||||
The excitation frequency is set to be 1kHz.
|
||||
</p>
|
||||
|
||||
<table id="org9d7793d" border="2" cellspacing="0" cellpadding="6" rules="groups" frame="hsides">
|
||||
<table id="org2ae85fd" border="2" cellspacing="0" cellpadding="6" rules="groups" frame="hsides">
|
||||
<caption class="t-above"><span class="table-number">Table 2:</span> Capacitance measured with the LCR meter. The excitation signal is a sinus at 1kHz</caption>
|
||||
|
||||
<colgroup>
|
||||
<col class="org-right" />
|
||||
<col class="org-left" />
|
||||
|
||||
<col class="org-right" />
|
||||
|
||||
@ -285,57 +317,57 @@ The excitation frequency is set to be 1kHz.
|
||||
</colgroup>
|
||||
<thead>
|
||||
<tr>
|
||||
<th scope="col" class="org-right"><b>APA Number</b></th>
|
||||
<th scope="col" class="org-left"> </th>
|
||||
<th scope="col" class="org-right"><b>Sensor Stack</b></th>
|
||||
<th scope="col" class="org-right"><b>Actuator Stacks</b></th>
|
||||
</tr>
|
||||
</thead>
|
||||
<tbody>
|
||||
<tr>
|
||||
<td class="org-right">1</td>
|
||||
<td class="org-left">APA 1</td>
|
||||
<td class="org-right">5.10</td>
|
||||
<td class="org-right">10.03</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-right">2</td>
|
||||
<td class="org-left">APA 2</td>
|
||||
<td class="org-right">4.99</td>
|
||||
<td class="org-right">9.85</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-right">3</td>
|
||||
<td class="org-left">APA 3</td>
|
||||
<td class="org-right">1.72</td>
|
||||
<td class="org-right">5.18</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-right">4</td>
|
||||
<td class="org-left">APA 4</td>
|
||||
<td class="org-right">4.94</td>
|
||||
<td class="org-right">9.82</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-right">5</td>
|
||||
<td class="org-left">APA 5</td>
|
||||
<td class="org-right">4.90</td>
|
||||
<td class="org-right">9.66</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-right">6</td>
|
||||
<td class="org-left">APA 6</td>
|
||||
<td class="org-right">4.99</td>
|
||||
<td class="org-right">9.91</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-right">7</td>
|
||||
<td class="org-left">APA 7</td>
|
||||
<td class="org-right">4.85</td>
|
||||
<td class="org-right">9.85</td>
|
||||
</tr>
|
||||
</tbody>
|
||||
</table>
|
||||
|
||||
<div class="warning" id="org5042148">
|
||||
<div class="warning" id="org7282231">
|
||||
<p>
|
||||
There is clearly a problem with APA300ML number 3
|
||||
</p>
|
||||
@ -344,12 +376,12 @@ There is clearly a problem with APA300ML number 3
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orgb8a1481" class="outline-2">
|
||||
<h2 id="orgb8a1481"><span class="section-number-2">4</span> Stiffness measurement</h2>
|
||||
<div id="outline-container-orgcd8f0b8" class="outline-2">
|
||||
<h2 id="orgcd8f0b8"><span class="section-number-2">4</span> Stiffness measurement</h2>
|
||||
<div class="outline-text-2" id="text-4">
|
||||
</div>
|
||||
<div id="outline-container-org21bc9b2" class="outline-3">
|
||||
<h3 id="org21bc9b2"><span class="section-number-3">4.1</span> APA test</h3>
|
||||
<div id="outline-container-org20509de" class="outline-3">
|
||||
<h3 id="org20509de"><span class="section-number-3">4.1</span> APA test</h3>
|
||||
<div class="outline-text-3" id="text-4-1">
|
||||
<div class="org-src-container">
|
||||
<pre class="src src-matlab">load(<span class="org-string">'meas_stiff_apa_1_x.mat'</span>, <span class="org-string">'t'</span>, <span class="org-string">'F'</span>, <span class="org-string">'d'</span>);
|
||||
@ -415,10 +447,204 @@ plot(F_l, F_l<span class="org-type">*</span>fit_l(1) <span class="org-type">+</s
|
||||
</div>
|
||||
</div>
|
||||
</div>
|
||||
<div id="outline-container-orgb3154e0" class="outline-2">
|
||||
<h2 id="orgb3154e0"><span class="section-number-2">5</span> Test-Bench Description</h2>
|
||||
<div id="outline-container-orgc5606b4" class="outline-2">
|
||||
<h2 id="orgc5606b4"><span class="section-number-2">5</span> Stroke measurement</h2>
|
||||
<div class="outline-text-2" id="text-5">
|
||||
<div class="note" id="orgc87eff8">
|
||||
<p>
|
||||
We here wish to estimate the stroke of the APA.
|
||||
</p>
|
||||
|
||||
<p>
|
||||
To do so, one side of the APA is fixed, and a displacement probe is located on the other side as shown in Figure <a href="#org51f6741">7</a>.
|
||||
</p>
|
||||
|
||||
<p>
|
||||
Then, a voltage is applied on either one or two stacks using a DAC and a voltage amplifier.
|
||||
</p>
|
||||
|
||||
<div class="note" id="orgef58353">
|
||||
<p>
|
||||
Here are the documentation of the equipment used for this test bench:
|
||||
</p>
|
||||
<ul class="org-ul">
|
||||
<li><b>Voltage Amplifier</b>: <a href="doc/PD200-V7-R1.pdf">PD200</a> with a gain of 20</li>
|
||||
<li><b>16bits DAC</b>: <a href="doc/IO131-OEM-Datasheet.pdf">IO313 Speedgoat card</a></li>
|
||||
<li><b>Displacement Probe</b>: <a href="doc/Millimar--3723046--BA--C1208-C1216-C1240--FR--2016-11-08.pdf">Millimar C1216 electronics</a> and <a href="doc/tmp3m0cvmue_7888038c-cdc8-48d8-a837-35de02760685.pdf">Millimar 1318 probe</a></li>
|
||||
</ul>
|
||||
|
||||
</div>
|
||||
|
||||
|
||||
<div id="org51f6741" class="figure">
|
||||
<p><img src="figs/CE0EF55E-07B7-461B-8CDB-98590F68D15B.jpeg" alt="CE0EF55E-07B7-461B-8CDB-98590F68D15B.jpeg" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 7: </span>Bench to measured the APA stroke</p>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org676705f" class="outline-3">
|
||||
<h3 id="org676705f"><span class="section-number-3">5.1</span> Voltage applied on one stack</h3>
|
||||
<div class="outline-text-3" id="text-5-1">
|
||||
<p>
|
||||
Let’s first look at the relation between the voltage applied to <b>one</b> stack to the displacement of the APA as measured by the displacement probe.
|
||||
</p>
|
||||
|
||||
<p>
|
||||
The applied voltage is shown in Figure <a href="#org46608eb">8</a>.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="org46608eb" class="figure">
|
||||
<p><img src="figs/apa_stroke_voltage_time.png" alt="apa_stroke_voltage_time.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 8: </span>Applied voltage as a function of time</p>
|
||||
</div>
|
||||
|
||||
<p>
|
||||
The obtained displacement is shown in Figure <a href="#org14e1b3b">9</a>.
|
||||
The displacement is set to zero at initial time when the voltage applied is -20V.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="org14e1b3b" class="figure">
|
||||
<p><img src="figs/apa_stroke_time_1s.png" alt="apa_stroke_time_1s.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 9: </span>Displacement as a function of time for all the APA300ML</p>
|
||||
</div>
|
||||
|
||||
<p>
|
||||
Finally, the displacement is shown as a function of the applied voltage in Figure <a href="#org18bcdf6">10</a>.
|
||||
We can clearly see that there is a problem with the APA 3.
|
||||
Also, there is a large hysteresis.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="org18bcdf6" class="figure">
|
||||
<p><img src="figs/apa_d_vs_V_1s.png" alt="apa_d_vs_V_1s.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 10: </span>Displacement as a function of the applied voltage</p>
|
||||
</div>
|
||||
|
||||
<div class="important" id="orgb2961f0">
|
||||
<p>
|
||||
We can clearly see from Figure <a href="#org18bcdf6">10</a> that there is a problem with the APA number 3.
|
||||
</p>
|
||||
|
||||
</div>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orgf6d51af" class="outline-3">
|
||||
<h3 id="orgf6d51af"><span class="section-number-3">5.2</span> Voltage applied on two stacks</h3>
|
||||
<div class="outline-text-3" id="text-5-2">
|
||||
<p>
|
||||
Now look at the relation between the voltage applied to the <b>two</b> other stacks to the displacement of the APA as measured by the displacement probe.
|
||||
</p>
|
||||
|
||||
<p>
|
||||
The obtained displacement is shown in Figure <a href="#org6aae24c">11</a>.
|
||||
The displacement is set to zero at initial time when the voltage applied is -20V.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="org6aae24c" class="figure">
|
||||
<p><img src="figs/apa_stroke_time_2s.png" alt="apa_stroke_time_2s.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 11: </span>Displacement as a function of time for all the APA300ML</p>
|
||||
</div>
|
||||
|
||||
<p>
|
||||
Finally, the displacement is shown as a function of the applied voltage in Figure <a href="#orgdf848b0">12</a>.
|
||||
We can clearly see that there is a problem with the APA 3.
|
||||
Also, there is a large hysteresis.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="orgdf848b0" class="figure">
|
||||
<p><img src="figs/apa_d_vs_V_2s.png" alt="apa_d_vs_V_2s.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 12: </span>Displacement as a function of the applied voltage</p>
|
||||
</div>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org5fada7f" class="outline-3">
|
||||
<h3 id="org5fada7f"><span class="section-number-3">5.3</span> Voltage applied on all three stacks</h3>
|
||||
<div class="outline-text-3" id="text-5-3">
|
||||
<p>
|
||||
Finally, we can combine the two measurements to estimate the relation between the displacement and the voltage applied to the <b>three</b> stacks (Figure <a href="#orge301ee3">13</a>).
|
||||
</p>
|
||||
|
||||
|
||||
<div id="orge301ee3" class="figure">
|
||||
<p><img src="figs/apa_d_vs_V_3s.png" alt="apa_d_vs_V_3s.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 13: </span>Displacement as a function of the applied voltage</p>
|
||||
</div>
|
||||
|
||||
<p>
|
||||
The obtained maximum stroke for all the APA are summarized in Table <a href="#org0ae8a54">3</a>.
|
||||
</p>
|
||||
|
||||
<table id="org0ae8a54" border="2" cellspacing="0" cellpadding="6" rules="groups" frame="hsides">
|
||||
<caption class="t-above"><span class="table-number">Table 3:</span> Measured maximum stroke</caption>
|
||||
|
||||
<colgroup>
|
||||
<col class="org-left" />
|
||||
|
||||
<col class="org-right" />
|
||||
</colgroup>
|
||||
<thead>
|
||||
<tr>
|
||||
<th scope="col" class="org-left"> </th>
|
||||
<th scope="col" class="org-right"><b>Stroke</b> \([\mu m]\)</th>
|
||||
</tr>
|
||||
</thead>
|
||||
<tbody>
|
||||
<tr>
|
||||
<td class="org-left">APA 1</td>
|
||||
<td class="org-right">373.2</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 2</td>
|
||||
<td class="org-right">365.5</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 3</td>
|
||||
<td class="org-right">181.7</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 4</td>
|
||||
<td class="org-right">359.7</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 5</td>
|
||||
<td class="org-right">361.5</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 6</td>
|
||||
<td class="org-right">363.9</td>
|
||||
</tr>
|
||||
|
||||
<tr>
|
||||
<td class="org-left">APA 7</td>
|
||||
<td class="org-right">358.4</td>
|
||||
</tr>
|
||||
</tbody>
|
||||
</table>
|
||||
</div>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org3248c3e" class="outline-2">
|
||||
<h2 id="org3248c3e"><span class="section-number-2">6</span> Test-Bench Description</h2>
|
||||
<div class="outline-text-2" id="text-6">
|
||||
<div class="note" id="org5db8c73">
|
||||
<p>
|
||||
Here are the documentation of the equipment used for this test bench:
|
||||
</p>
|
||||
@ -433,21 +659,21 @@ Here are the documentation of the equipment used for this test bench:
|
||||
</div>
|
||||
|
||||
|
||||
<div id="orgfd15602" class="figure">
|
||||
<div id="org0400f6b" class="figure">
|
||||
<p><img src="figs/test_bench_apa_alone.png" alt="test_bench_apa_alone.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 7: </span>Schematic of the Test Bench</p>
|
||||
<p><span class="figure-number">Figure 14: </span>Schematic of the Test Bench</p>
|
||||
</div>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orgac581ad" class="outline-2">
|
||||
<h2 id="orgac581ad"><span class="section-number-2">6</span> Measurement Procedure</h2>
|
||||
<div class="outline-text-2" id="text-6">
|
||||
<div id="outline-container-orgabbb81c" class="outline-2">
|
||||
<h2 id="orgabbb81c"><span class="section-number-2">7</span> Measurement Procedure</h2>
|
||||
<div class="outline-text-2" id="text-7">
|
||||
</div>
|
||||
<div id="outline-container-orge00396f" class="outline-3">
|
||||
<h3 id="orge00396f"><span class="section-number-3">6.1</span> Stroke Measurement</h3>
|
||||
<div class="outline-text-3" id="text-6-1">
|
||||
<div id="outline-container-orge3152f8" class="outline-3">
|
||||
<h3 id="orge3152f8"><span class="section-number-3">7.1</span> Stroke Measurement</h3>
|
||||
<div class="outline-text-3" id="text-7-1">
|
||||
<p>
|
||||
Using the PD200 amplifier, output a voltage:
|
||||
\[ V_a = 65 + 85 \sin(2\pi \cdot t) \]
|
||||
@ -474,9 +700,9 @@ Conclude on the obtained stroke.
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org66ac5bb" class="outline-3">
|
||||
<h3 id="org66ac5bb"><span class="section-number-3">6.2</span> Stiffness Measurement</h3>
|
||||
<div class="outline-text-3" id="text-6-2">
|
||||
<div id="outline-container-orgc1cf00d" class="outline-3">
|
||||
<h3 id="orgc1cf00d"><span class="section-number-3">7.2</span> Stiffness Measurement</h3>
|
||||
<div class="outline-text-3" id="text-7-2">
|
||||
<p>
|
||||
Add some (known) weight \(\delta m g\) on the suspended mass and measure the deflection \(\delta d\).
|
||||
This can be tested when the piezoelectric stacks are open-circuit.
|
||||
@ -495,9 +721,9 @@ Then the obtained stiffness is:
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orgee2d3e8" class="outline-3">
|
||||
<h3 id="orgee2d3e8"><span class="section-number-3">6.3</span> Hysteresis measurement</h3>
|
||||
<div class="outline-text-3" id="text-6-3">
|
||||
<div id="outline-container-org61adc4b" class="outline-3">
|
||||
<h3 id="org61adc4b"><span class="section-number-3">7.3</span> Hysteresis measurement</h3>
|
||||
<div class="outline-text-3" id="text-7-3">
|
||||
<p>
|
||||
Supply a quasi static sinusoidal excitation \(V_a\) at different voltages.
|
||||
</p>
|
||||
@ -515,17 +741,17 @@ Then, \(d\) is plotted as a function of \(V_a\) for all the amplitudes.
|
||||
</p>
|
||||
|
||||
|
||||
<div id="org7123135" class="figure">
|
||||
<div id="org0fb5c18" class="figure">
|
||||
<p><img src="figs/expected_hysteresis.png" alt="expected_hysteresis.png" />
|
||||
</p>
|
||||
<p><span class="figure-number">Figure 8: </span>Expected Hysteresis (<a class='org-ref-reference' href="#poel10_explor_activ_hard_mount_vibrat">poel10_explor_activ_hard_mount_vibrat</a>)</p>
|
||||
<p><span class="figure-number">Figure 15: </span>Expected Hysteresis (<a class='org-ref-reference' href="#poel10_explor_activ_hard_mount_vibrat">poel10_explor_activ_hard_mount_vibrat</a>)</p>
|
||||
</div>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orge6e89ca" class="outline-3">
|
||||
<h3 id="orge6e89ca"><span class="section-number-3">6.4</span> Piezoelectric Actuator Constant</h3>
|
||||
<div class="outline-text-3" id="text-6-4">
|
||||
<div id="outline-container-org3c6cfed" class="outline-3">
|
||||
<h3 id="org3c6cfed"><span class="section-number-3">7.4</span> Piezoelectric Actuator Constant</h3>
|
||||
<div class="outline-text-3" id="text-7-4">
|
||||
<p>
|
||||
Using the measurement test-bench, it is rather easy the determine the static gain between the applied voltage \(V_a\) to the induced displacement \(d\).
|
||||
Use a quasi static (1Hz) excitation signal \(V_a\) on the piezoelectric stack and measure the vertical displacement \(d\).
|
||||
@ -551,9 +777,9 @@ From the two gains, it is then easy to determine \(g_a\):
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orge970d07" class="outline-3">
|
||||
<h3 id="orge970d07"><span class="section-number-3">6.5</span> Piezoelectric Sensor Constant</h3>
|
||||
<div class="outline-text-3" id="text-6-5">
|
||||
<div id="outline-container-org9c52d3c" class="outline-3">
|
||||
<h3 id="org9c52d3c"><span class="section-number-3">7.5</span> Piezoelectric Sensor Constant</h3>
|
||||
<div class="outline-text-3" id="text-7-5">
|
||||
<p>
|
||||
From a quasi static excitation of the piezoelectric stack, measure the gain from \(V_a\) to \(V_s\):
|
||||
</p>
|
||||
@ -591,18 +817,18 @@ This external force can be some weight added, or a piezo in parallel.
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org86b3954" class="outline-3">
|
||||
<h3 id="org86b3954"><span class="section-number-3">6.6</span> Capacitance Measurement</h3>
|
||||
<div class="outline-text-3" id="text-6-6">
|
||||
<div id="outline-container-org30f8839" class="outline-3">
|
||||
<h3 id="org30f8839"><span class="section-number-3">7.6</span> Capacitance Measurement</h3>
|
||||
<div class="outline-text-3" id="text-7-6">
|
||||
<p>
|
||||
Measure the capacitance of the 3 stacks individually using a precise multi-meter.
|
||||
</p>
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-orgc5205df" class="outline-3">
|
||||
<h3 id="orgc5205df"><span class="section-number-3">6.7</span> Dynamical Behavior</h3>
|
||||
<div class="outline-text-3" id="text-6-7">
|
||||
<div id="outline-container-org7549456" class="outline-3">
|
||||
<h3 id="org7549456"><span class="section-number-3">7.7</span> Dynamical Behavior</h3>
|
||||
<div class="outline-text-3" id="text-7-7">
|
||||
<p>
|
||||
Perform a system identification from \(V_a\) to the measured displacement \(d\) by the interferometer and by the encoder, and to the generated voltage \(V_s\).
|
||||
</p>
|
||||
@ -617,9 +843,9 @@ This can also be performed with and without the encoder fixed to the APA.
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org2f73a1b" class="outline-3">
|
||||
<h3 id="org2f73a1b"><span class="section-number-3">6.8</span> Compare the results obtained for all 7 APA300ML</h3>
|
||||
<div class="outline-text-3" id="text-6-8">
|
||||
<div id="outline-container-org51816a1" class="outline-3">
|
||||
<h3 id="org51816a1"><span class="section-number-3">7.8</span> Compare the results obtained for all 7 APA300ML</h3>
|
||||
<div class="outline-text-3" id="text-7-8">
|
||||
<p>
|
||||
Compare all the obtained parameters for all the test APA.
|
||||
</p>
|
||||
@ -627,8 +853,8 @@ Compare all the obtained parameters for all the test APA.
|
||||
</div>
|
||||
</div>
|
||||
|
||||
<div id="outline-container-org175e8d0" class="outline-2">
|
||||
<h2 id="org175e8d0"><span class="section-number-2">7</span> Measurement Results</h2>
|
||||
<div id="outline-container-org0b4e69a" class="outline-2">
|
||||
<h2 id="org0b4e69a"><span class="section-number-2">8</span> Measurement Results</h2>
|
||||
</div>
|
||||
|
||||
<style>.csl-entry{text-indent: -1.5em; margin-left: 1.5em;}</style><h2 class='citeproc-org-bib-h2'>Bibliography</h2>
|
||||
@ -638,7 +864,7 @@ Compare all the obtained parameters for all the test APA.
|
||||
</div>
|
||||
<div id="postamble" class="status">
|
||||
<p class="author">Author: Dehaeze Thomas</p>
|
||||
<p class="date">Created: 2021-03-15 lun. 11:35</p>
|
||||
<p class="date">Created: 2021-03-16 mar. 14:30</p>
|
||||
</div>
|
||||
</body>
|
||||
</html>
|
||||
|
||||
@ -108,6 +108,8 @@ The block-diagram model of the piezoelectric actuator is then as shown in Figure
|
||||
* Geometrical Measurements
|
||||
** Introduction :ignore:
|
||||
|
||||
The received APA are shown in Figure [[fig:received_apa]].
|
||||
|
||||
#+name: fig:received_apa
|
||||
#+caption: Received APA
|
||||
#+attr_latex: :width 0.6\linewidth
|
||||
@ -133,13 +135,16 @@ addpath('./mat/');
|
||||
|
||||
** Measurement Setup
|
||||
|
||||
The flatness corresponding to the two interface planes are measured as shown in Figure [[fig:flatness_meas_setup]].
|
||||
|
||||
#+name: fig:flatness_meas_setup
|
||||
#+caption: Measurement Setup
|
||||
#+attr_latex: :width 0.6\linewidth
|
||||
[[file:figs/IMG_20210224_143809.jpg]]
|
||||
|
||||
** Measurement Results
|
||||
Height (Z) measurements:
|
||||
|
||||
The height (Z) measurements at the 8 locations (4 points by plane) are defined below.
|
||||
#+begin_src matlab
|
||||
apa1 = 1e-6*[0, -0.5 , 3.5 , 3.5 , 42 , 45.5, 52.5 , 46];
|
||||
apa2 = 1e-6*[0, -2.5 , -3 , 0 , -1.5 , 1 , -2 , -4];
|
||||
@ -152,7 +157,7 @@ apa7b = 1e-6*[0, 9 , -18.5, -30 , 31 , 46.5, 16.5 , 7.5];
|
||||
apa = {apa1, apa2, apa3, apa4, apa5, apa6, apa7b};
|
||||
#+end_src
|
||||
|
||||
X/Y Positions of the 8 measurement points:
|
||||
The X/Y Positions of the 8 measurement points are defined below.
|
||||
#+begin_src matlab
|
||||
W = 20e-3; % Width [m]
|
||||
L = 61e-3; % Length [m]
|
||||
@ -162,6 +167,7 @@ l = 15.5e-3; % [m]
|
||||
pos = [[-L/2 + d; W/2 - d], [-L/2 + l - d; W/2 - d], [-L/2 + l - d; -W/2 + d], [-L/2 + d; -W/2 + d], [L/2 - l + d; W/2 - d], [L/2 - d; W/2 - d], [L/2 - d; -W/2 + d], [L/2 - l + d; -W/2 + d]];
|
||||
#+end_src
|
||||
|
||||
Finally, the flatness is estimated by fitting a plane through the 8 points using the =fminsearch= command.
|
||||
#+begin_src matlab
|
||||
apa_d = zeros(1, 7);
|
||||
for i = 1:7
|
||||
@ -172,24 +178,26 @@ for i = 1:7
|
||||
end
|
||||
#+end_src
|
||||
|
||||
The obtained flatness are shown in Table [[tab:flatness_meas]].
|
||||
|
||||
#+begin_src matlab :exports results :results value table replace :tangle no :post addhdr(*this*)
|
||||
data2orgtable(1e6*apa_d', {}, {'Flatness [um]'}, ' %.1f ');
|
||||
data2orgtable(1e6*apa_d', {'APA 1', 'APA 2', 'APA 3', 'APA 4', 'APA 5', 'APA 6', 'APA 7'}, {'*Flatness* $[\mu m]$'}, ' %.1f ');
|
||||
#+end_src
|
||||
|
||||
#+name: tab:flatness_meas
|
||||
#+caption: Estimated flatness
|
||||
#+attr_latex: :environment tabularx :width \linewidth :align c
|
||||
#+attr_latex: :environment tabularx :width 0.25\linewidth :align lc
|
||||
#+attr_latex: :center t :booktabs t :float t
|
||||
#+RESULTS:
|
||||
| Flatness [um] |
|
||||
|---------------|
|
||||
| 8.9 |
|
||||
| 3.1 |
|
||||
| 9.1 |
|
||||
| 3.0 |
|
||||
| 1.9 |
|
||||
| 7.1 |
|
||||
| 18.7 |
|
||||
| | *Flatness* $[\mu m]$ |
|
||||
|-------+----------------------|
|
||||
| APA 1 | 8.9 |
|
||||
| APA 2 | 3.1 |
|
||||
| APA 3 | 9.1 |
|
||||
| APA 4 | 3.0 |
|
||||
| APA 5 | 1.9 |
|
||||
| APA 6 | 7.1 |
|
||||
| APA 7 | 18.7 |
|
||||
|
||||
* Electrical Measurements
|
||||
|
||||
@ -206,23 +214,41 @@ The excitation frequency is set to be 1kHz.
|
||||
|
||||
#+name: tab:apa300ml_capacitance
|
||||
#+caption: Capacitance measured with the LCR meter. The excitation signal is a sinus at 1kHz
|
||||
#+attr_latex: :environment tabularx :width 0.6\linewidth :align lcc
|
||||
#+attr_latex: :environment tabularx :width 0.5\linewidth :align lcc
|
||||
#+attr_latex: :center t :booktabs t :float t
|
||||
| *APA Number* | *Sensor Stack* | *Actuator Stacks* |
|
||||
|--------------+----------------+-------------------|
|
||||
| 1 | 5.10 | 10.03 |
|
||||
| 2 | 4.99 | 9.85 |
|
||||
| 3 | 1.72 | 5.18 |
|
||||
| 4 | 4.94 | 9.82 |
|
||||
| 5 | 4.90 | 9.66 |
|
||||
| 6 | 4.99 | 9.91 |
|
||||
| 7 | 4.85 | 9.85 |
|
||||
| | *Sensor Stack* | *Actuator Stacks* |
|
||||
|-------+----------------+-------------------|
|
||||
| APA 1 | 5.10 | 10.03 |
|
||||
| APA 2 | 4.99 | 9.85 |
|
||||
| APA 3 | 1.72 | 5.18 |
|
||||
| APA 4 | 4.94 | 9.82 |
|
||||
| APA 5 | 4.90 | 9.66 |
|
||||
| APA 6 | 4.99 | 9.91 |
|
||||
| APA 7 | 4.85 | 9.85 |
|
||||
|
||||
#+begin_warning
|
||||
There is clearly a problem with APA300ML number 3
|
||||
#+end_warning
|
||||
|
||||
* Stiffness measurement
|
||||
** Matlab Init :noexport:ignore:
|
||||
#+begin_src matlab :tangle no :exports none :results silent :noweb yes :var current_dir=(file-name-directory buffer-file-name)
|
||||
<<matlab-dir>>
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :exports none :results silent :noweb yes
|
||||
<<matlab-init>>
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no
|
||||
addpath('./matlab/mat/');
|
||||
addpath('./matlab/');
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :eval no
|
||||
addpath('./mat/');
|
||||
#+end_src
|
||||
|
||||
** APA test
|
||||
#+begin_src matlab
|
||||
load('meas_stiff_apa_1_x.mat', 't', 'F', 'd');
|
||||
@ -277,6 +303,267 @@ plot(F,d,'k')
|
||||
plot(F_l, d_l)
|
||||
plot(F_l, F_l*fit_l(1) + fit_l(2), '--')
|
||||
#+end_src
|
||||
* Stroke measurement
|
||||
** Introduction :ignore:
|
||||
|
||||
We here wish to estimate the stroke of the APA.
|
||||
|
||||
To do so, one side of the APA is fixed, and a displacement probe is located on the other side as shown in Figure [[fig:stroke_test_bench]].
|
||||
|
||||
Then, a voltage is applied on either one or two stacks using a DAC and a voltage amplifier.
|
||||
|
||||
#+begin_note
|
||||
Here are the documentation of the equipment used for this test bench:
|
||||
- *Voltage Amplifier*: [[file:doc/PD200-V7-R1.pdf][PD200]] with a gain of 20
|
||||
- *16bits DAC*: [[file:doc/IO131-OEM-Datasheet.pdf][IO313 Speedgoat card]]
|
||||
- *Displacement Probe*: [[file:doc/Millimar--3723046--BA--C1208-C1216-C1240--FR--2016-11-08.pdf][Millimar C1216 electronics]] and [[file:doc/tmp3m0cvmue_7888038c-cdc8-48d8-a837-35de02760685.pdf][Millimar 1318 probe]]
|
||||
#+end_note
|
||||
|
||||
#+name: fig:stroke_test_bench
|
||||
#+caption: Bench to measured the APA stroke
|
||||
#+attr_latex: :width 0.9\linewidth
|
||||
[[file:figs/CE0EF55E-07B7-461B-8CDB-98590F68D15B.jpeg]]
|
||||
|
||||
** Matlab Init :noexport:ignore:
|
||||
#+begin_src matlab :tangle no :exports none :results silent :noweb yes :var current_dir=(file-name-directory buffer-file-name)
|
||||
<<matlab-dir>>
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :exports none :results silent :noweb yes
|
||||
<<matlab-init>>
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no
|
||||
addpath('./matlab/mat/');
|
||||
addpath('./matlab/');
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :eval no
|
||||
addpath('./mat/');
|
||||
#+end_src
|
||||
|
||||
** Voltage applied on one stack
|
||||
|
||||
Let's first look at the relation between the voltage applied to *one* stack to the displacement of the APA as measured by the displacement probe.
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
apa300ml_1s = {};
|
||||
for i = 1:7
|
||||
apa300ml_1s(i) = {load(['mat/stroke_apa_1stacks_' num2str(i) '.mat'], 't', 'V', 'd')};
|
||||
end
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
for i = 1:7
|
||||
t = apa300ml_1s{i}.t;
|
||||
apa300ml_1s{i}.d = apa300ml_1s{i}.d - mean(apa300ml_1s{i}.d(t > 1.9 & t < 2.0));
|
||||
apa300ml_1s{i}.d = apa300ml_1s{i}.d(t > 2.0 & t < 10.0);
|
||||
apa300ml_1s{i}.V = apa300ml_1s{i}.V(t > 2.0 & t < 10.0);
|
||||
apa300ml_1s{i}.t = apa300ml_1s{i}.t(t > 2.0 & t < 10.0);
|
||||
end
|
||||
#+end_src
|
||||
|
||||
The applied voltage is shown in Figure [[fig:apa_stroke_voltage_time]].
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
figure;
|
||||
plot(apa300ml_1s{1}.t, 20*apa300ml_1s{1}.V)
|
||||
xlabel('Time [s]'); ylabel('Voltage [V]');
|
||||
ylim([-20,160]); yticks([-20 0 20 40 60 80 100 120 140 160]);
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no :exports results :results file replace
|
||||
exportFig('figs/apa_stroke_voltage_time.pdf', 'width', 'wide', 'height', 'normal');
|
||||
#+end_src
|
||||
|
||||
#+name: fig:apa_stroke_voltage_time
|
||||
#+caption: Applied voltage as a function of time
|
||||
#+RESULTS:
|
||||
[[file:figs/apa_stroke_voltage_time.png]]
|
||||
|
||||
The obtained displacement is shown in Figure [[fig:apa_stroke_time_1s]].
|
||||
The displacement is set to zero at initial time when the voltage applied is -20V.
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
figure;
|
||||
hold on;
|
||||
for i = 1:7
|
||||
plot(apa300ml_1s{i}.t, 1e6*apa300ml_1s{i}.d, 'DisplayName', sprintf('APA %i', i))
|
||||
end
|
||||
hold off;
|
||||
xlabel('Time [s]'); ylabel('Displacement [$\mu m$]')
|
||||
legend('location', 'southeast', 'FontSize', 8)
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no :exports results :results file replace
|
||||
exportFig('figs/apa_stroke_time_1s.pdf', 'width', 'wide', 'height', 'normal');
|
||||
#+end_src
|
||||
|
||||
#+name: fig:apa_stroke_time_1s
|
||||
#+caption: Displacement as a function of time for all the APA300ML
|
||||
#+RESULTS:
|
||||
[[file:figs/apa_stroke_time_1s.png]]
|
||||
|
||||
Finally, the displacement is shown as a function of the applied voltage in Figure [[fig:apa_d_vs_V_1s]].
|
||||
We can clearly see that there is a problem with the APA 3.
|
||||
Also, there is a large hysteresis.
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
figure;
|
||||
hold on;
|
||||
for i = 1:7
|
||||
plot(20*apa300ml_1s{i}.V, 1e6*apa300ml_1s{i}.d, 'DisplayName', sprintf('APA %i', i))
|
||||
end
|
||||
hold off;
|
||||
xlabel('Voltage [V]'); ylabel('Displacement [$\mu m$]')
|
||||
legend('location', 'southwest', 'FontSize', 8)
|
||||
xlim([-20, 160]); ylim([-140, 0]);
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no :exports results :results file replace
|
||||
exportFig('figs/apa_d_vs_V_1s.pdf', 'width', 'wide', 'height', 'tall');
|
||||
#+end_src
|
||||
|
||||
#+name: fig:apa_d_vs_V_1s
|
||||
#+caption: Displacement as a function of the applied voltage
|
||||
#+RESULTS:
|
||||
[[file:figs/apa_d_vs_V_1s.png]]
|
||||
|
||||
#+begin_important
|
||||
We can clearly see from Figure [[fig:apa_d_vs_V_1s]] that there is a problem with the APA number 3.
|
||||
#+end_important
|
||||
|
||||
** Voltage applied on two stacks
|
||||
|
||||
Now look at the relation between the voltage applied to the *two* other stacks to the displacement of the APA as measured by the displacement probe.
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
apa300ml_2s = {};
|
||||
for i = 1:7
|
||||
apa300ml_2s(i) = {load(['mat/stroke_apa_2stacks_' num2str(i) '.mat'], 't', 'V', 'd')};
|
||||
end
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
for i = 1:7
|
||||
t = apa300ml_2s{i}.t;
|
||||
apa300ml_2s{i}.d = apa300ml_2s{i}.d - mean(apa300ml_2s{i}.d(t > 1.9 & t < 2.0));
|
||||
apa300ml_2s{i}.d = apa300ml_2s{i}.d(t > 2.0 & t < 10.0);
|
||||
apa300ml_2s{i}.V = apa300ml_2s{i}.V(t > 2.0 & t < 10.0);
|
||||
apa300ml_2s{i}.t = apa300ml_2s{i}.t(t > 2.0 & t < 10.0);
|
||||
end
|
||||
#+end_src
|
||||
|
||||
The obtained displacement is shown in Figure [[fig:apa_stroke_time_2s]].
|
||||
The displacement is set to zero at initial time when the voltage applied is -20V.
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
figure;
|
||||
hold on;
|
||||
for i = 1:7
|
||||
plot(apa300ml_2s{i}.t, 1e6*apa300ml_2s{i}.d, 'DisplayName', sprintf('APA %i', i))
|
||||
end
|
||||
hold off;
|
||||
xlabel('Time [s]'); ylabel('Displacement [$\mu m$]')
|
||||
legend('location', 'southeast', 'FontSize', 8)
|
||||
ylim([-250, 0]);
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no :exports results :results file replace
|
||||
exportFig('figs/apa_stroke_time_2s.pdf', 'width', 'wide', 'height', 'normal');
|
||||
#+end_src
|
||||
|
||||
#+name: fig:apa_stroke_time_2s
|
||||
#+caption: Displacement as a function of time for all the APA300ML
|
||||
#+RESULTS:
|
||||
[[file:figs/apa_stroke_time_2s.png]]
|
||||
|
||||
Finally, the displacement is shown as a function of the applied voltage in Figure [[fig:apa_d_vs_V_2s]].
|
||||
We can clearly see that there is a problem with the APA 3.
|
||||
Also, there is a large hysteresis.
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
figure;
|
||||
hold on;
|
||||
for i = 1:7
|
||||
plot(20*apa300ml_2s{i}.V, 1e6*apa300ml_2s{i}.d, 'DisplayName', sprintf('APA %i', i))
|
||||
end
|
||||
hold off;
|
||||
xlabel('Voltage [V]'); ylabel('Displacement [$\mu m$]')
|
||||
legend('location', 'southwest', 'FontSize', 8)
|
||||
xlim([-20, 160]); ylim([-250, 0]);
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no :exports results :results file replace
|
||||
exportFig('figs/apa_d_vs_V_2s.pdf', 'width', 'wide', 'height', 'tall');
|
||||
#+end_src
|
||||
|
||||
#+name: fig:apa_d_vs_V_2s
|
||||
#+caption: Displacement as a function of the applied voltage
|
||||
#+RESULTS:
|
||||
[[file:figs/apa_d_vs_V_2s.png]]
|
||||
|
||||
** Voltage applied on all three stacks
|
||||
|
||||
Finally, we can combine the two measurements to estimate the relation between the displacement and the voltage applied to the *three* stacks (Figure [[fig:apa_d_vs_V_3s]]).
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
apa300ml_3s = {};
|
||||
for i = 1:7
|
||||
apa300ml_3s(i) = apa300ml_1s(i);
|
||||
apa300ml_3s{i}.d = apa300ml_1s{i}.d + apa300ml_2s{i}.d;
|
||||
end
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
figure;
|
||||
hold on;
|
||||
for i = 1:7
|
||||
plot(20*apa300ml_3s{i}.V, 1e6*apa300ml_3s{i}.d, 'DisplayName', sprintf('APA %i', i))
|
||||
end
|
||||
hold off;
|
||||
xlabel('Voltage [V]'); ylabel('Displacement [$\mu m$]')
|
||||
legend('location', 'southwest', 'FontSize', 8)
|
||||
xlim([-20, 160]); ylim([-400, 0]);
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :tangle no :exports results :results file replace
|
||||
exportFig('figs/apa_d_vs_V_3s.pdf', 'width', 'wide', 'height', 'tall');
|
||||
#+end_src
|
||||
|
||||
#+name: fig:apa_d_vs_V_3s
|
||||
#+caption: Displacement as a function of the applied voltage
|
||||
#+RESULTS:
|
||||
[[file:figs/apa_d_vs_V_3s.png]]
|
||||
|
||||
The obtained maximum stroke for all the APA are summarized in Table [[tab:apa_measured_stroke]].
|
||||
|
||||
#+begin_src matlab :exports none
|
||||
apa300ml_stroke = zeros(1, 7);
|
||||
for i = 1:7
|
||||
apa300ml_stroke(i) = max(apa300ml_3s{i}.d) - min(apa300ml_3s{i}.d);
|
||||
end
|
||||
#+end_src
|
||||
|
||||
#+begin_src matlab :exports results :results value table replace :tangle no :post addhdr(*this*)
|
||||
data2orgtable(1e6*apa300ml_stroke', {'APA 1', 'APA 2', 'APA 3', 'APA 4', 'APA 5', 'APA 6', 'APA 7'}, {'*Stroke* $[\mu m]$'}, ' %.1f ');
|
||||
#+end_src
|
||||
|
||||
#+name: tab:apa_measured_stroke
|
||||
#+caption: Measured maximum stroke
|
||||
#+attr_latex: :environment tabularx :width 0.25\linewidth :align lc
|
||||
#+attr_latex: :center t :booktabs t :float t
|
||||
#+RESULTS:
|
||||
| | *Stroke* $[\mu m]$ |
|
||||
|-------+--------------------|
|
||||
| APA 1 | 373.2 |
|
||||
| APA 2 | 365.5 |
|
||||
| APA 3 | 181.7 |
|
||||
| APA 4 | 359.7 |
|
||||
| APA 5 | 361.5 |
|
||||
| APA 6 | 363.9 |
|
||||
| APA 7 | 358.4 |
|
||||
|
||||
