1 Amplified Piezoelectric Actuator - 3D elements

The idea here is to:

export a FEM of an amplified piezoelectric actuator from Ansys to Matlab
import it into a Simscape model
compare the obtained dynamics
add 10kg mass on top of the actuator and identify the dynamics
compare with results from Ansys where 10kg are directly added to the FEM

1.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

We first extract the stiffness and mass matrices.

K = extractMatrix('piezo_amplified_3d_K.txt');
M = extractMatrix('piezo_amplified_3d_M.txt');

Then, we extract the coordinates of the interface nodes.

[int_xyz, int_i, n_xyz, n_i, nodes] = extractNodes('piezo_amplified_3d.txt');

save('./mat/piezo_amplified_3d.mat', 'int_xyz', 'int_i', 'n_xyz', 'n_i', 'nodes', 'M', 'K');

1.2 Output parameters

load('./mat/piezo_amplified_3d.mat', 'int_xyz', 'int_i', 'n_xyz', 'n_i', 'nodes', 'M', 'K');

Total number of Nodes	168959
Number of interface Nodes	13
Number of Modes	30
Size of M and K matrices	108

Figure 1: Interface Nodes for the Amplified Piezo Actuator

Table 1: Coordinates of the interface nodes
Node i	Node Number	x [m]	y [m]
1.0	168947.0	0.0	0.03
2.0	168949.0	0.0	-0.03
3.0	168950.0	-0.035	0.0
4.0	168951.0	-0.028	0.0
5.0	168952.0	-0.021	0.0
6.0	168953.0	-0.014	0.0
7.0	168954.0	-0.007	0.0
8.0	168955.0	0.0	0.0
9.0	168956.0	0.007	0.0
10.0	168957.0	0.014	0.0
11.0	168958.0	0.021	0.0
12.0	168959.0	0.035	0.0
13.0	168960.0	0.028	0.0

Table 2: First 10x10 elements of the Stiffness matrix
300000000.0	-30000.0	8000.0	-200.0	-30.0	-60000.0	20000000.0	-4000.0	500.0	8
-30000.0	100000000.0	400.0	30.0	200.0	-1	4000.0	-8000000.0	800.0	7
8000.0	400.0	50000000.0	-800000.0	-300.0	-40.0	300.0	100.0	5000000.0	40000.0
-200.0	30.0	-800000.0	20000.0	5	1	-10.0	-2	-40000.0	-300.0
-30.0	200.0	-300.0	5	40000.0	0.3	-4	-10.0	40.0	0.4
-60000.0	-1	-40.0	1	0.3	3000.0	7000.0	0.8	-1	0.0003
20000000.0	4000.0	300.0	-10.0	-4	7000.0	300000000.0	20000.0	3000.0	80.0
-4000.0	-8000000.0	100.0	-2	-10.0	0.8	20000.0	100000000.0	-4000.0	-100.0
500.0	800.0	5000000.0	-40000.0	40.0	-1	3000.0	-4000.0	50000000.0	800000.0
8	7	40000.0	-300.0	0.4	0.0003	80.0	-100.0	800000.0	20000.0

Table 3: First 10x10 elements of the Mass matrix
0.03	2e-06	-2e-07	1e-08	2e-08	0.0002	-0.001	2e-07	-8e-08	-9e-10
2e-06	0.02	-5e-07	7e-09	3e-08	2e-08	-3e-07	0.0003	-1e-08	1e-10
-2e-07	-5e-07	0.02	-9e-05	4e-09	-1e-08	2e-07	-2e-08	-0.0006	-5e-06
1e-08	7e-09	-9e-05	1e-06	6e-11	4e-10	-1e-09	3e-11	5e-06	3e-08
2e-08	3e-08	4e-09	6e-11	1e-06	2e-10	-2e-09	2e-10	-7e-09	-4e-11
0.0002	2e-08	-1e-08	4e-10	2e-10	2e-06	-2e-06	-1e-09	-7e-10	-9e-12
-0.001	-3e-07	2e-07	-1e-09	-2e-09	-2e-06	0.03	-2e-06	-1e-07	-5e-09
2e-07	0.0003	-2e-08	3e-11	2e-10	-1e-09	-2e-06	0.02	-8e-07	-1e-08
-8e-08	-1e-08	-0.0006	5e-06	-7e-09	-7e-10	-1e-07	-8e-07	0.02	9e-05
-9e-10	1e-10	-5e-06	3e-08	-4e-11	-9e-12	-5e-09	-1e-08	9e-05	1e-06

Using K, M and int_xyz, we can use the Reduced Order Flexible Solid simscape block.

1.3 Piezoelectric parameters

Parameters for the APA95ML:

d33 = 3e-10; % Strain constant [m/V]
n = 80; % Number of layers per stack
eT = 1.6e-7; % Permittivity under constant stress [F/m]
sD = 2e-11; % Elastic compliance under constant electric displacement [m2/N]
ka = 235e6; % Stack stiffness [N/m]
C = 5e-6; % Stack capactiance [F]

na = 2; % Number of stacks used as actuator
ns = 1; % Number of stacks used as force sensor

The ratio of the developed force to applied voltage is \(d_{33} n k_a\) in [N/V]. We denote this constant by \(g_a\) and: \[ F_a = g_a V_a, \quad g_a = d_{33} n k_a \]

d33*(na*n)*(ka/(na + ns)) % [N/V]

3.76

From (Fleming and Leang 2014) (page 123), the relation between relative displacement and generated voltage is: \[ V_s = \frac{d_{33}}{\epsilon^T s^D n} \Delta h \] where:

\(V_s\): measured voltage [V]
\(d_{33}\): strain constant [m/V]
\(\epsilon^T\): permittivity under constant stress [F/m]
\(s^D\): elastic compliance under constant electric displacement [m^2/N]
\(n\): number of layers
\(\Delta h\): relative displacement [m]

1e-6*d33/(eT*sD*ns*n) % [V/um]

1.1719

1.4 Identification of the Dynamics

The flexible element is imported using the Reduced Order Flexible Solid simscape block.

To model the actuator, an Internal Force block is added between the nodes 3 and 12. A Relative Motion Sensor block is added between the nodes 1 and 2 to measure the displacement and the amplified piezo.

One mass is fixed at one end of the piezo-electric stack actuator, the other end is fixed to the world frame.

We first set the mass to be zero.

m = 0.01;

The dynamics is identified from the applied force to the measured relative displacement.

%% Name of the Simulink File
mdl = 'piezo_amplified_3d';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/F'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/y'], 1, 'openoutput'); io_i = io_i + 1;

Gh = -linearize(mdl, io);

Then, we add 10Kg of mass:

m = 5;

And the dynamics is identified.

The two identified dynamics are compared in Figure 2.

%% Name of the Simulink File
mdl = 'piezo_amplified_3d';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/F'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/y'], 1, 'openoutput'); io_i = io_i + 1;

Ghm = -linearize(mdl, io);

Figure 2: Dynamics from \(F\) to \(d\) without a payload and with a 10kg payload

1.5 Comparison with Ansys

Let’s import the results from an Harmonic response analysis in Ansys.

Gresp0 = readtable('FEA_HarmResponse_00kg.txt');
Gresp10 = readtable('FEA_HarmResponse_10kg.txt');

The obtained dynamics from the Simscape model and from the Ansys analysis are compare in Figure 3.

Figure 3: Comparison of the obtained dynamics using Simscape with the harmonic response analysis using Ansys

1.6 Force Sensor

The dynamics is identified from internal forces applied between nodes 3 and 11 to the relative displacement of nodes 11 and 13.

The obtained dynamics is shown in Figure 4.

m = 0;

%% Name of the Simulink File
mdl = 'piezo_amplified_3d';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/Fa'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/Fs'], 1, 'openoutput'); io_i = io_i + 1;

Gf = linearize(mdl, io);

m = 10;

%% Name of the Simulink File
mdl = 'piezo_amplified_3d';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/Fa'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/Fs'], 1, 'openoutput'); io_i = io_i + 1;

Gfm = linearize(mdl, io);

Figure 4: Dynamics from \(F\) to \(F_m\) for \(m=0\) and \(m = 10kg\)

1.7 Distributed Actuator

m = 0;

The dynamics is identified from the applied force to the measured relative displacement.

%% Name of the Simulink File
mdl = 'piezo_amplified_3d_distri';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/F'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/y'], 1, 'openoutput'); io_i = io_i + 1;

Gd = linearize(mdl, io);

Then, we add 10Kg of mass:

m = 10;

And the dynamics is identified.

%% Name of the Simulink File
mdl = 'piezo_amplified_3d_distri';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/F'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/y'], 1, 'openoutput'); io_i = io_i + 1;

Gdm = linearize(mdl, io);

1.8 Distributed Actuator and Force Sensor

m = 0;

%% Name of the Simulink File
mdl = 'piezo_amplified_3d_distri_act_sens';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/F'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/Fm'], 1, 'openoutput'); io_i = io_i + 1;

Gfd = linearize(mdl, io);

m = 10;

%% Name of the Simulink File
mdl = 'piezo_amplified_3d_distri_act_sens';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/F'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/Fm'], 1, 'openoutput'); io_i = io_i + 1;

Gfdm = linearize(mdl, io);

1.9 Dynamics from input voltage to displacement

m = 5;

And the dynamics is identified.

The two identified dynamics are compared in Figure 2.

%% Name of the Simulink File
mdl = 'piezo_amplified_3d';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/V'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/y'], 1, 'openoutput'); io_i = io_i + 1;

G = -linearize(mdl, io);

save('../test-bench-apa/mat/fem_model_5kg.mat', 'G')

1.10 Dynamics from input voltage to output voltage

m = 5;

%% Name of the Simulink File
mdl = 'piezo_amplified_3d';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/Va'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/Vs'], 1, 'openoutput'); io_i = io_i + 1;

G = -linearize(mdl, io);

2 APA300ML

Figure 5: Ansys FEM of the APA300ML

2.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

We first extract the stiffness and mass matrices.

K = extractMatrix('mat_K-48modes-7MDoF.matrix');
M = extractMatrix('mat_M-48modes-7MDoF.matrix');

K = extractMatrix('mat_K-80modes-7MDoF.matrix');
M = extractMatrix('mat_M-80modes-7MDoF.matrix');

Then, we extract the coordinates of the interface nodes.

[int_xyz, int_i, n_xyz, n_i, nodes] = extractNodes('Nodes_MDoF_NLIST_MLIST.txt');

save('./mat/APA300ML.mat', 'int_xyz', 'int_i', 'n_xyz', 'n_i', 'nodes', 'M', 'K');

2.2 Output parameters

load('./mat/APA300ML.mat', 'int_xyz', 'int_i', 'n_xyz', 'n_i', 'nodes', 'M', 'K');

Total number of Nodes	7
Number of interface Nodes	7
Number of Modes	6
Size of M and K matrices	48

Table 4: Coordinates of the interface nodes
Node i	Node Number	x [m]	y [m]
1.0	53917.0	0.0	-0.015
2.0	53918.0	0.0	0.015
3.0	53919.0	-0.0325	0.0
4.0	53920.0	-0.0125	0.0
5.0	53921.0	-0.0075	0.0
6.0	53922.0	0.0125	0.0
7.0	53923.0	0.0325	0.0

Table 5: First 10x10 elements of the Stiffness matrix
200000000.0	30000.0	50000.0	200.0	-100.0	-300000.0	10000000.0	-6000.0	20000.0	-60.0
30000.0	7000000.0	10000.0	30.0	-30.0	-70.0	7000.0	-500000.0	3000.0	-10.0
50000.0	10000.0	30000000.0	200000.0	-200.0	-100.0	20000.0	-2000.0	2000000.0	-9000.0
200.0	30.0	200000.0	1000.0	-0.8	-0.4	50.0	-6	9000.0	-30.0
-100.0	-30.0	-200.0	-0.8	10000.0	0.2	-40.0	10.0	20.0	-0.05
-300000.0	-70.0	-100.0	-0.4	0.2	900.0	-30000.0	10.0	-40.0	0.1
10000000.0	7000.0	20000.0	50.0	-40.0	-30000.0	200000000.0	-50000.0	30000.0	-50.0
-6000.0	-500000.0	-2000.0	-6	10.0	10.0	-50000.0	7000000.0	-4000.0	8
20000.0	3000.0	2000000.0	9000.0	20.0	-40.0	30000.0	-4000.0	30000000.0	-200000.0
-60.0	-10.0	-9000.0	-30.0	-0.05	0.1	-50.0	8	-200000.0	1000.0

Table 6: First 10x10 elements of the Mass matrix
0.01	7e-06	-5e-06	-6e-08	3e-09	-5e-05	-0.0005	-2e-07	-3e-06	1e-08
7e-06	0.009	4e-07	6e-09	-4e-09	-3e-08	-2e-07	6e-05	5e-07	-1e-09
-5e-06	4e-07	0.01	2e-05	2e-08	3e-08	-2e-06	-1e-07	-0.0002	9e-07
-6e-08	6e-09	2e-05	3e-07	1e-10	3e-10	-7e-09	2e-10	-9e-07	3e-09
3e-09	-4e-09	2e-08	1e-10	1e-07	-3e-12	6e-09	-2e-10	-3e-09	9e-12
-5e-05	-3e-08	3e-08	3e-10	-3e-12	6e-07	1e-06	-3e-09	2e-08	-7e-11
-0.0005	-2e-07	-2e-06	-7e-09	6e-09	1e-06	0.01	-8e-06	-2e-06	9e-09
-2e-07	6e-05	-1e-07	2e-10	-2e-10	-3e-09	-8e-06	0.009	1e-07	2e-09
-3e-06	5e-07	-0.0002	-9e-07	-3e-09	2e-08	-2e-06	1e-07	0.01	-2e-05
1e-08	-1e-09	9e-07	3e-09	9e-12	-7e-11	9e-09	2e-09	-2e-05	3e-07

Using K, M and int_xyz, we can use the Reduced Order Flexible Solid simscape block.

2.3 Piezoelectric parameters

Parameters for the APA95ML:

d33 = 3e-10; % Strain constant [m/V]
n = 80; % Number of layers per stack
eT = 1.6e-8; % Permittivity under constant stress [F/m]
sD = 2e-11; % Elastic compliance under constant electric displacement [m2/N]
ka = 235e6; % Stack stiffness [N/m]
C = 5e-6; % Stack capactiance [F]

na = 3; % Number of stacks used as actuator
ns = 0; % Number of stacks used as force sensor

The ratio of the developed force to applied voltage is \(d_{33} n k_a\) in [N/V]. We denote this constant by \(g_a\) and: \[ F_a = g_a V_a, \quad g_a = d_{33} n k_a \]

d33*(na*n)*(ka/(na + ns)) % [N/V]

1.88

From (Fleming and Leang 2014) (page 123), the relation between relative displacement and generated voltage is: \[ V_s = \frac{d_{33}}{\epsilon^T s^D n} \Delta h \] where:

\(V_s\): measured voltage [V]
\(d_{33}\): strain constant [m/V]
\(\epsilon^T\): permittivity under constant stress [F/m]
\(s^D\): elastic compliance under constant electric displacement [m^2/N]
\(n\): number of layers
\(\Delta h\): relative displacement [m]

1e-6*d33/(eT*sD*ns*n) % [V/um]

5.8594

2.4 Identification of the APA Characteristics

2.4.1 Stiffness

The transfer function from vertical external force to the relative vertical displacement is identified.

The inverse of its DC gain is the axial stiffness of the APA:

1e-6/dcgain(G) % [N/um]

1.8634

The specified stiffness in the datasheet is \(k = 1.8\, [N/\mu m]\).

2.4.2 Resonance Frequency

The resonance frequency is specified to be between 650Hz and 840Hz. This is also the case for the FEM model (Figure 6).

Figure 6: First resonance is around 800Hz

2.4.3 Amplification factor

The amplification factor is the ratio of the axial displacement to the stack displacement.

The ratio of the two displacement is computed from the FEM model.

-dcgain(G(1,1))./dcgain(G(2,1))

4.936

If we take the ratio of the piezo height and length (approximation of the amplification factor):

75/15

2.4.4 Stroke

Estimation of the actuator stroke: \[ \Delta H = A n \Delta L \] with:

\(\Delta H\) Axial Stroke of the APA
\(A\) Amplification factor (5 for the APA300ML)
\(n\) Number of stack used
\(\Delta L\) Stroke of the stack (0.1% of its length)

1e6 * 5 * 3 * 20e-3 * 0.1e-2

This is exactly the specified stroke in the data-sheet.

2.5 Identification of the Dynamics

The flexible element is imported using the Reduced Order Flexible Solid simscape block.

One mass is fixed at one end of the piezo-electric stack actuator, the other end is fixed to the world frame.

We first set the mass to be zero. The dynamics is identified from the applied force to the measured relative displacement. The same dynamics is identified for a payload mass of 10Kg.

m = 10;

Figure 7: Transfer function from forces applied by the stack to the axial displacement of the APA

2.6 IFF

Let’s use 2 stacks as actuators and 1 stack as force sensor.

The transfer function from actuator to sensors is identified and shown in Figure 8.

Figure 8: Transfer function from actuator to force sensor

For root locus corresponding to IFF is shown in Figure 9.

Figure 9: Root Locus for IFF

2.7 DVF

Now the dynamics from the stack actuator to the relative motion sensor is identified and shown in Figure 10.

Figure 10: Transfer function from stack actuator to relative motion sensor

The root locus for DVF is shown in Figure 11.

Figure 11: Root Locus for Direct Velocity Feedback

3 Flexible Joint

Figure 12: Flexor studied

3.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

We first extract the stiffness and mass matrices.

K = extractMatrix('mat_K_6modes_2MDoF.matrix');
M = extractMatrix('mat_M_6modes_2MDoF.matrix');

Then, we extract the coordinates of the interface nodes.

[int_xyz, int_i, n_xyz, n_i, nodes] = extractNodes('out_nodes_3D.txt');

save('./mat/flexor_ID16.mat', 'int_xyz', 'int_i', 'n_xyz', 'n_i', 'nodes', 'M', 'K');

3.2 Output parameters

load('./mat/flexor_ID16.mat', 'int_xyz', 'int_i', 'n_xyz', 'n_i', 'nodes', 'M', 'K');

Total number of Nodes	2
Number of interface Nodes	2
Number of Modes	6
Size of M and K matrices	18

Table 7: Coordinates of the interface nodes
Node i	Node Number	x [m]	y [m]	z [m]
1.0	181278.0	0.0	0.0	0.0
2.0	181279.0	0.0	0.0	-0.0

Table 8: First 10x10 elements of the Stiffness matrix
11200000.0	195.0	2220.0	-0.719	-265.0	1.59	-11200000.0	-213.0	-2220.0	0.147
195.0	11400000.0	1290.0	-148.0	-0.188	2.41	-212.0	-11400000.0	-1290.0	148.0
2220.0	1290.0	119000000.0	1.31	1.49	1.79	-2220.0	-1290.0	-119000000.0	-1.31
-0.719	-148.0	1.31	33.0	0.000488	-0.000977	0.141	148.0	-1.31	-33.0
-265.0	-0.188	1.49	0.000488	33.0	0.00293	266.0	0.154	-1.49	0.00026
1.59	2.41	1.79	-0.000977	0.00293	236.0	-1.32	-2.55	-1.79	0.000379
-11200000.0	-212.0	-2220.0	0.141	266.0	-1.32	11400000.0	24600.0	1640.0	120.0
-213.0	-11400000.0	-1290.0	148.0	0.154	-2.55	24600.0	11400000.0	1290.0	-72.0
-2220.0	-1290.0	-119000000.0	-1.31	-1.49	-1.79	1640.0	1290.0	119000000.0	1.32
0.147	148.0	-1.31	-33.0	0.00026	0.000379	120.0	-72.0	1.32	34.7

Table 9: First 10x10 elements of the Mass matrix
0.02	1e-09	-4e-08	-1e-10	0.0002	-3e-11	0.004	5e-08	7e-08	1e-10
1e-09	0.02	-3e-07	-0.0002	-1e-10	-2e-09	2e-08	0.004	3e-07	1e-05
-4e-08	-3e-07	0.02	7e-10	-2e-09	1e-09	3e-07	7e-08	0.003	1e-09
-1e-10	-0.0002	7e-10	4e-06	-1e-12	-6e-13	2e-10	-7e-06	-8e-10	-1e-09
0.0002	-1e-10	-2e-09	-1e-12	3e-06	2e-13	9e-06	4e-11	2e-09	-3e-13
-3e-11	-2e-09	1e-09	-6e-13	2e-13	4e-07	8e-11	9e-10	-1e-09	2e-12
0.004	2e-08	3e-07	2e-10	9e-06	8e-11	0.02	-7e-08	-3e-07	-2e-10
5e-08	0.004	7e-08	-7e-06	4e-11	9e-10	-7e-08	0.01	-4e-08	0.0002
7e-08	3e-07	0.003	-8e-10	2e-09	-1e-09	-3e-07	-4e-08	0.02	-1e-09
1e-10	1e-05	1e-09	-1e-09	-3e-13	2e-12	-2e-10	0.0002	-1e-09	2e-06

Using K, M and int_xyz, we can use the Reduced Order Flexible Solid simscape block.

3.3 Flexible Joint Characteristics

Caracteristic	Value	Estimation by Francois
Axial Stiffness [N/um]	119	60
Bending Stiffness [Nm/rad]	33	15
Bending Stiffness [Nm/rad]	33	15
Torsion Stiffness [Nm/rad]	236	20

3.4 Identification

m = 10;

The dynamics is identified from the applied force to the measured relative displacement.

%% Name of the Simulink File
mdl = 'flexor_ID16';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/T'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/D'], 1, 'openoutput'); io_i = io_i + 1;

G = linearize(mdl, io);

Caracteristic	Value	Identification
Axial Stiffness Dz [N/um]	119	119
Bending Stiffness Rx [Nm/rad]	33	34
Bending Stiffness Ry [Nm/rad]	33	126
Torsion Stiffness Rz [Nm/rad]	236	238

4 Integral Force Feedback with Amplified Piezo

In this section, we try to replicate the results obtained in (Souleille et al. 2018).

4.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

We first extract the stiffness and mass matrices.

K = extractMatrix('piezo_amplified_IFF_K.txt');
M = extractMatrix('piezo_amplified_IFF_M.txt');

Then, we extract the coordinates of the interface nodes.

[int_xyz, int_i, n_xyz, n_i, nodes] = extractNodes('piezo_amplified_IFF.txt');

4.2 IFF Plant

The transfer function from the force actuator to the force sensor is identified and shown in Figure 13.

Kiff = tf(0);

m = 0;

%% Name of the Simulink File
mdl = 'piezo_amplified_IFF';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/Kiff'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/G'],    1, 'openoutput'); io_i = io_i + 1;

Gf = linearize(mdl, io);

m = 10;

Gfm = linearize(mdl, io);

Figure 13: IFF Plant

4.3 IFF controller

The controller is defined and the loop gain is shown in Figure 14.

Kiff = -1e12/s;

Figure 14: IFF Loop Gain

4.4 Closed Loop System

m = 10;

Kiff = -1e12/s;

%% Name of the Simulink File
mdl = 'piezo_amplified_IFF';

%% Input/Output definition
clear io; io_i = 1;
io(io_i) = linio([mdl, '/Dw'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/F'],  1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/Fd'], 1, 'openinput');  io_i = io_i + 1;
io(io_i) = linio([mdl, '/d'],  1, 'openoutput'); io_i = io_i + 1;
io(io_i) = linio([mdl, '/G'],  1, 'output'); io_i = io_i + 1;

Giff = linearize(mdl, io);
Giff.InputName  = {'w', 'f', 'F'};
Giff.OutputName  = {'x1', 'Fs'};

Kiff = tf(0);

G = linearize(mdl, io);
G.InputName  = {'w', 'f', 'F'};
G.OutputName  = {'x1', 'Fs'};

Figure 15: OL and CL transfer functions

Figure 16: Results obtained in souleille18_concep_activ_mount_space_applic

Bibliography

Fleming, Andrew J., and Kam K. Leang. 2014. Design, Modeling and Control of Nanopositioning Systems. Advances in Industrial Control. Springer International Publishing. https://doi.org/10.1007/978-3-319-06617-2.

Souleille, Adrien, Thibault Lampert, V Lafarga, Sylvain Hellegouarch, Alan Rondineau, Gonçalo Rodrigues, and Christophe Collette. 2018. “A Concept of Active Mount for Space Applications.” CEAS Space Journal 10 (2). Springer:157–65.

Finite Element Model with Simscape

Table of Contents

1 Amplified Piezoelectric Actuator - 3D elements

1.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

1.2 Output parameters

1.3 Piezoelectric parameters

1.4 Identification of the Dynamics

1.5 Comparison with Ansys

1.6 Force Sensor

1.7 Distributed Actuator

1.8 Distributed Actuator and Force Sensor

1.9 Dynamics from input voltage to displacement

1.10 Dynamics from input voltage to output voltage

2 APA300ML

2.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

2.2 Output parameters

2.3 Piezoelectric parameters

2.4 Identification of the APA Characteristics

2.4.1 Stiffness

2.4.2 Resonance Frequency

2.4.3 Amplification factor

2.4.4 Stroke

2.5 Identification of the Dynamics

2.6 IFF

2.7 DVF

3 Flexible Joint

3.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

3.2 Output parameters

3.3 Flexible Joint Characteristics

3.4 Identification

4 Integral Force Feedback with Amplified Piezo

4.1 Import Mass Matrix, Stiffness Matrix, and Interface Nodes Coordinates

4.2 IFF Plant

4.3 IFF controller

4.4 Closed Loop System

Bibliography
